SG0000
SunGuard is a newly developed fabric series which have been designed to help shield out the suns harmful UV rays, heat and glare while maintaining optimum visibility.
SunGuard fabric’s features include an exceptional rolling performance, combined with strong dimensional stability and low stretch which makes it suitable for retractable shading systems. It’s light weight offers greater flexibility without affecting its resistance to difficult weather conditions and mechanical strain.
SunGuard fabrics have an extremely regular and consistent look, with a perfectly smooth, satin finish, which reduces the adhesion of dirt and makes cleaning easier. The micro-aerated structure and the regular weave guarantees optimal visual comfort and gives off a harmonious light
Specially designed for buildings that have big window areas (offices, museums, public buildings). SunGuard is today a low-cost and natural alternative that meets the latest standards in terms of solar protection.
Technical characteristics
Composition | 100% polyester, PVC coated, both side lacquered | |
Weight | 360g/m2±5% | GB/T4669-2008 |
Thickness | 0.45mm±5% | FZ/T01003-1991 |
Tensile Strength | Warp 250N/5cm,Weft 200N/5cm | DIN53354:1981 |
Tearing Strength | Warp 120N, Weft 90N | DIN53363:2003 |
Elongation | Warp 20%,Weft 25% | |
Openness Factor | 5% | FZ/T01009-2008 |
Color Fastness | 8/7/4.5 | GB/T8427-2008/ ISO 105 B02/ ATCC |
Fire Resistance | B2(Oxygen.Index≥27mm)/NFPA701/M2 | GB 50222-95/ NFPA701/ NFP92-503 |
UV screen | Approx. 95% | |
Environment | HJ/T307-2006 OEKO-TEX STANDARD 100CLASS ZV GREEN GUARD ECOSPECIFIER CETEC | |
Pattern | lamination | |
Making-up | high frequency welding, ultrasonic welding, | |
Width | 2.0M/2.5M/3.0M | |
Length | 27.4m/roll | GB/T4669-2008 |
